HR-317 Series

With the internal RFID card reader feature of Artech HR Kiosk, your employees can safely enter the HR system of your company. With its stainless steel industrial keyboard and A4 thermal printer feature, Artech HR Kiosk allows your employees to perform HR operations such as payroll printouts, requesting duties and permits, filling out training forms and satisfaction surveys as self-service, quickly.

In case your employees and HR department are in different locations, video calls can be made with Artech HR Kiosk's internal Camera-Microphone-Speaker feature, and the interaction and trust between the Company and the Employee can be increased.

  • HR Kiosk Preference in Desired Configuration
  • Internal RFID Staff Card Reader
  • Built-in A4 Thermal Printer Feature
  • Internal Stainless Steel Industrial Keyboard and Track Ball
  • Internal Camera-Microphone-Speaker
  • Customizing with Corporate Color and Logo
  • Vandal Resistance
Vandal Resistance
Vandal Resistance
Customizing with Corporate Color and Logo
Customizing with Corporate Color and Logo
Ergonomic Design
Ergonomic Design
Kiosk in Desired Configuration
Kiosk in Desired Configuration
Industrial Stainless Steel Body
Industrial Stainless Steel Body

Sectors

Technical Specifications

System
CPU :
Intel® iCore™ Processor i5
Memory :
4 GB
Video RAM :
Internal
Chipset :
SOC
Watchdog Timer :
255 Level Reset
System Fan :
1 x 4cm / 10CFM
I/O
Serial Port :
2
Parallel Port :
N.A.
USB Port :
4
KB / MS :
Internal Stainless Steel Industrial Keyboard and Track-Ball
LAN :
1 x LAN Realtek Gigabit Ethernet
Wireless LAN :
802.11 b / g (Optional)
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
MiniPCIe
Readers :
RFID Mifare (Optional)
Writer :
Thermal A4 Printer (Anti-Jam, Automatic Cutter, Automatic Retract)
Data Storage
HDD / Type :
2.5” HDD/SSD
Feed
Input :
Internal industrial type 250W
Power (Max) :
110 / 220VAC veya 12 / 24VDC
LCD Screen
Type and Size :
17" / 4:3
Max. Resolution :
1280x1024, XGA
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
350
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 Hours
Touch Screen :
Capacitive
Extra Video Output
Type :
2. LCD Screen 19"
Max. Resolution :
1280 x 800
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy Duty
Weight :
Variable according to the screen size (35 kg)
Mounting :
Floor Standing
Order Code
CPU :
i5
RAM :
AC110/220 / DC12/24
HDD :
HDD 320GB / SSD 32GB / SSD 64GB
RFID Reader :
Optional
Writer :
Termal A4 Printer
Barcode Reader :
Mifare
