DPC-332 Series

"Digital Signage System", which is the most effective communication instrument used by many companies operating in different sectors all over the world today; has the advantages of cost efficiency, time saving, multi-purpose use, real-time announcement publishing and creating a prestigious corporate image.

Artech Professional Information Displays,stand out with the ability to be managed from a single center and publish different contents

  • Corporate Color Options
  • Stylish Design Suitable for Elevator Structure
  • Shockproof Stainless Metal Body
  • 3mm. Anti-Glare Unbreakable Glass
  • Protection Against Dust and Humidity with Sensitive Filter
  • Remote Connection Problem Analysis and Solution
Custom Design
Custom Design
Sustainable Product
Sustainable Product
Support with Remote Connection
Support with Remote Connection

Sectors

Technical Specifications

System
CPU :
Intel® Celeron j1900 / Intel® Icore i5/i7
Cache :
2nd Level depends on CPU
Memory :
4GB
Video RAM :
Max 128 MB shared memory
Control :
Intel® Soc / QM77
Watchdog Timer :
255 Level Reset
System Fan :
N.A.
I/O
Serial Port :
N.A.
USB Port :
2 x USB 2.0
LAN :
1 x LAN Realtek Gigabit Ethernet
Audio :
5W Speaker (Optional)
Data Storage
HDD / Type :
Vibration Resistant Slot 2.5 ”(500 GB HDD)
SSD :
64 GB / 128GB / 256 GB
Feed
Input :
220VAC or 24VDC
LCD Screen
Type and Size :
32" LVDS
Max. Resolution :
1920x1080
Pixel Pitch :
0.311mm x 0.311mm
Max Color :
16.7 M
Brightness (cd/m2) :
350cd
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Extra Video Output
Type :
HDMI (Optional)
Max. Resolution :
1920x1080(Optional)
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Metal Frame / Glass (Optional)
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Surface Mount / Built-in
Order Code
CPU :
J1900, i5, i7
PSU :
AC - 220VAC
RAM :
R4
HDD :
HDD 500GB(OPS), SSD64, SSD128, SSD256
Wifi :
N.A
