DPC-355 Series

Artech Professional Information Display: Optimal Solution for Digital Broadcasts

The Artech DPC-355 Series Professional Information Displays are specifically designed for digital broadcasting systems, providing a flawless, maintenance-free device that meets all their requirements. These 55-inch displays offer the most common and effective communication solution to reach your target audience. They feature a shock-resistant stainless steel body, 4mm anti-glare shatterproof glass, and precise filtering for superior protection against dust and humidity. Additionally, remote connection capabilities for problem analysis and resolution simplify your technical support processes.

Key Features:

Shock-Resistant Metal Body: Ensures long-lasting use with a robust structure.
4mm Anti-Glare Shatterproof Glass: Non-reflective and resistant to breakage.
Precise Filtering: Effective protection against dust and humidity.
Remote Connection: Facilitates rapid analysis and resolution of issues via remote technical support.
Corporate Logo and Color Options: Customization to align with your brand's aesthetics.

Sustainable Product

Support with Remote Connection

Customizing with Corporate Color and Logo

Sectors

Technical Specifications

System

CPU :

Intel® Celeron j1900 / Intel® Icore i5/i7

Cache :

2nd Level depends on CPU

Memory :

4GB

Video RAM :

Max 128 MB shared memory

Control :

Intel® Soc / QM77

Watchdog Timer :

255 Level Reset

System Fan :

N.A.

I/O

Serial Port :

N.A.

USB Port :

2 x USB 2.0

LAN :

1 x LAN Realtek Gigabit Ethernet

Audio :

3W Stereo Output / 5W Speaker (Optional)

Data Storage

HDD / Type :

Vibration Resistant Slot 2.5 ”(500 GB HDD)

SSD :

64 GB / 128GB / 256 GB

Feed

Input :

220VAC or 24VDC

Extra Video Output

Type :

HDMI/DP/DVI/VGA Optional)

Max. Resolution :

1920x1080(2560x1600 Optional)

LCD Screen

Type and Size :

55" LVDS

Max. Resolution :

1920x1080

Pixel Pitch :

0.630mm x 0.630mm

Max Color :

16.7 M

Brightness (cd/m2) :

450cd

Contrast Ratio :

1000/1

Viewing Angle :

178°(H),178°(V)

Back Light MTBF :

50,000 hours

Mechanical & Environmental Features

Operating Temperature :

0 ~ 60°C

Storage Humidity :

5 ~ 95% (non-condensing)

Case :

Heavy-Duty Metal Case

Front Frame :

Metal Frame / Glass (Optional)

Weight :

Variable according to screen size (1—5 kg)

Dimensions :

(WxHxD) Variable by screen size

Mounting :

Surface Mount / Built-in

Order Code

CPU :

J1900, i5, i7

PSU :

AC - 220VAC

RAM :

HDD :

HDD 500GB(OPS), SSD64, SSD128, SSD256

Wifi :

N.A
