OPC-310 Series

Areas of usage; door information systems, meeting rooms or conference rooms door information systems and in interactive kiosk systems for routing and informing.

  • Access to Patient Information with HIS
  • Slim Industrial Stainless Case
  • 0-60 ° C Operating Temperature
  • Corporate Color and Logo Options
  • Low Power Consumption and Longer Backlight Half-Life with Optional Auto Backlight Adjustment Sensor
Elegant Design
Elegant Design
Customizing with Corporate Color and Logo
Customizing with Corporate Color and Logo
Durable and Long Lasting
Durable and Long Lasting

Sectors

Technical Specifications

System
CPU :
Intel® Celeron N2930 SoC
Cache :
N.A.
Memory :
1 x 204-pin DDR3L-1333 SO-DIMM up to 8GB
Video RAM :
Intel HD Graphics, 313MHz - 854MHz
Control :
Intel® NM10 / QM77
Watchdog Timer :
255 Level Reset
System Fan :
1 x 4cm / 10CFM
I/O
Serial Port :
Serial port headers (3 * RS232, 1 * RS232/422/485)
Parallel Port :
SPP/EPP/ECP
USB Port :
4 x (USB 2.0/3.0)
KB / MS :
1 x PS2 K/B and Mouse
LAN :
2 x Realtek RTL8111G Gigabit LAN with Enhanced Surge Protection
Wireless LAN :
802.11 b / g (Optional)
Audio :
Realtek ALC662 HD Audio codec
Expansion Slot :
mSATA/mini-PCI Express Combo slot
Data Storage
SSD :
M-SATA
Feed
Input :
110 / 220VAC - 12 / 24VDC - PoE
LCD Screen
Backlight Half-Life :
30,000 hours
Type and Size :
11.6” / 16:9
Max. Resolution :
1280 x 800
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
250cd
Contrast Ratio :
700/1
Viewing Angle :
140°(H),120°(V)
Touch Screen :
11.6” - Capacitive Touch
Extra Video Output
Type :
HDMI/DVI
Max. Resolution :
1920x1080
Mechanical & Environmental Features
Order Code
CPU :
J1900
PSU :
AC110/220, DC12/24, PoE
RAM :
R4, R8
HDD :
32GB
Wifi :
Optional

Support

Please contact us for information about the products or for technical support.
