OPC-315 Series

Artech Door Information Displays: Custom Solutions for Corporate Identity and Architecture

Artech Door Information Displays are designed for use in various environments such as hotels, hospitals, meeting rooms, and conference halls for direction and information purposes. These displays can be customized to complement your corporate identity and architectural decor. They can publish current information and announcements featuring a durable, industrial stainless steel case and operating temperature range from 0-60°C. They also offer remote connection capabilities for instant problem analysis and resolution, quickly addressing technical issues.

Key Features:

  • Custom Design to Fit Corporate Identity: Tailored design options to match your space and brand.
  • Versatile Use in Various Environments: Ideal for hotels, hospitals, meetings, and conference facilities.
  • Current Information Publishing: Easily share event announcements and current updates.
  • Durable Construction: Industrial stainless steel housing with a wide operating temperature range.
  • Remote Technical Support: Remote connection support for problem analysis and resolution.
Elegant Design
Elegant Design
Customizing with Corporate Color and Logo
Customizing with Corporate Color and Logo
Durable and Long Lasting
Durable and Long Lasting

Sectors

Technical Specifications

System
CPU :
Intel® Celeron™ Processor J1900 Low Power Fanless
Cache :
2MB
Memory :
2 x DDR3 SoDIMM max 4GB / 8GB
Video RAM :
Max 128 MB shared memory
Control :
N.A.
Watchdog Timer :
255 Level Reset
System Fan :
1 x 4cm / 10CFM
I/O
Serial Port :
3 x RS-232 ports
Parallel Port :
N.A.
USB Port :
4 x USB 2.0
KB / MS :
1 x PS2 K/B and Mouse
LAN :
1 x LAN Realtek Gigabit Ethernet,
Wireless LAN :
802.11 b / g (Optional)
Audio :
Line in & out (AC’97 codec audio)
Expansion Slot :
MiniPCIe
Data Storage
HDD / Type :
2.5” HDD/SSD
Feed
Input :
110 / 220VAC - 12 / 24VDC - PoE
Extra Video Output
Type :
HDMI
Max. Resolution :
1920x1080
LCD Screen
Type and Size :
15" / 4:3
Max. Resolution :
1024 x 768, XGA
Pixel Pitch :
0.297mm x 0.297mm
Max Color :
16.7 M
Brightness (cd/m2) :
350
Contrast Ratio :
1000/1
Viewing Angle :
160°(H),160°(V)
Back Light MTBF :
50,000 hours
Touch Screen :
N.A
Mechanical & Environmental Features
Operating Temperature :
0 ~ 60°C
Storage Humidity :
5 ~ 95% (non-condensing)
Case :
Heavy-Duty Metal Case
Front Frame :
Glass
Weight :
Variable according to screen size (1—5 kg)
Dimensions :
(WxHxD) Variable by screen size
Mounting :
Built-in
Order Code
CPU :
J1900
PSU :
AC110/220, DC12/24, PoE
RAM :
R4, R8
HDD :
HDD 320GB, SSD 32 GB, SSD 64 GB
Wifi :
Optional

Support

Please contact us for information about the products or for technical support.
